Management features Web-based management Yes show more Quality of Service (QoS) support Yes show more Web-based setup wizard Yes show more WPS push button Yes show more Reset button Yes show more Security Security algorithms 128-bit WEP, 64-bit WEP, AES, TKIP, WPA, WPA2, WPA2-TKIP, WPA-TKIP show more DMZ support Yes show more MAC address filtering Yes show more Access Control List (ACL) Yes show more IP address filtering Yes show more Parental control Yes show more Ports & interfaces Ethernet LAN (RJ-45) ports 3 show more USB port No show more Memory card slot(s) No show more DC-in jack Yes show more Network Ethernet LAN data rates 10,100 Mbit/s show more Ethernet LAN Yes show more Networking standards IEEE 802.11b, IEEE 802.11g, IEEE 802.11n show more Ethernet LAN interface type Fast Ethernet show more Dynamic DNS (DDNS) Yes show more Port forwarding Yes show more Receiver sensitivity - 270M: -61 dBm@10% PER - 135M: -65 dBm@10% PER - 54M: -68 dBm@10% PER - 11M: -85 dBm@8% PER - 6M: -88 dBm@10% PER - 1M: -90 dBm@8% PER show more Cabling technology 10/100Base-T(X) show more Features Plug and Play Yes show more Firmware upgradeable Yes show more Design Product color White show more Built-in display No show more Product type Tabletop router show more LED indicators ADSL, LAN, Link, Power, System, WLAN show more Housing material Acrylonitrile butadiene styrene (ABS), Plastic show more On/off switch Yes show more Indication light Yes show more Packaging data Package type Box show more Operational conditions Storage relative humidity (H-H) 5 - 90 show more Storage temperature (T-T) -40 - 70 show more Operating relative humidity (H-H) 10 - 90 show more Operating temperature (T-T) 0 - 50 show more WAN connection Ethernet WAN Yes show more DSL WAN Yes show more SIM card slot No show more 3G/4G USB modem compatibility No show more WAN connection type RJ-11 show more Wireless LAN features Wi-Fi band Single-band (2.4 GHz) show more Top Wi-Fi standard Wi-Fi 4 (802.11n) show more WLAN data transfer rate (max) 300 Mbit/s show more Wi-Fi standards 802.11b, 802.11g, Wi-Fi 4 (802.11n) show more Packaging content Cables included DC, LAN (RJ-45), Phone (RJ-11) show more Antenna included Yes show more Quick installation guide Yes show more AC adapter included Yes show more DSL features ADSL Yes show more ADSL2 Yes show more ADSL2 Yes show more Protocols DHCP client Yes show more DHCP server Yes show more Universal Plug and Play (UPnP) Yes show more Power Power supply 7.2000 show more Output voltage 9 V show more Power source type DC show more Power over Ethernet (PoE) No show more AC input voltage 100 - 240 V show more Power consumption (typical) 7.2000 show more Output current 0.8000 show more AC input frequency 50 - 60 Hz show more Antenna Antenna design External show more Detachable antenna(s) Yes show more Antenna gain level (max) 5 dBi show more Antennas quantity 2 show more Weight & dimensions Depth 99 mm show more Width 122 mm show more Height 55 mm show more
